ROOK
Product Overview
Design-wise, the ROOK is another team player for all your HERON setups, but it can deliver a king’s performance on its own! This powerful surface-mounted exterior light can do wonders for your outdoor areas. The ROOK can help you make your parking lots and pathways safer or accentuate the beauty of your buildings with some well-placed facade lights. Combine the ROOK with our ground-mounted HERON lights and enjoy world-class architectural design without breaking the bank.
Basic colours
Specification
V
220 - 240
Hz
50 - 60
W
15 - 28
lm
1 845 - 3 890 1
lm/W
119 - 143
K
2700 / 3000 / 4000 2
°C
-40 to +40
CRI
>80 / >90 2
Body: Die-cast aluminium
Dimming: DALI / 1-10 V / Midnight dimming / Step dimming / Mains dimming
Initial chromaticity: MacAdam 5
Lifetime: Eco 100 000 h (L90B10) at Ta = 25 °C* /
Standard / High density 100 000 h (L98B10) at Ta = 25 °C*
Warranty: 5 years
Mounting: On wall
Surge protection: 4 / 6 / 10 kV 3
Nature friendly: PC Amber / Red / 1800 K
Corrosion protection: Up to C5
Neto weight: Up to 3.3 kg
Max. wind load area, SCd: 0.015 m2
Download Documents
Download product information
Features
Electronics
Controls & Connectivity
Light
Optics
Terminal blocks and plugs
