COLIBRI
Product Overview
Colibri can be the missing link in urban projects of any scale. With the best price-performance ratio on the market. Small in size, simple yet thoughtful in design, will solve different challenges with the unprecedented value of the Colibri street luminaires.
Basic colours
Specification
V
198 - 264
Hz
50 - 60
W
5 - 50
lm
450 - 7 025 1
lm/W
91 - 159
K
2700 / 3000 / 4000 2
°C
-40 up to +55 3
CRI
>70 / >80 / >90 2
in
400 x 165 x 78
Body: Die-cast aluminium
Dimming: DALI / 1-10 V / Midnight dimming / Step dimming / Mains dimming
Initial chromaticity: MacAdam 5
Lifetime: Eco 100 000 h (L90B10) at Ta = 25 °C* /
Standard / High density 100 000 h (L98B10) at Ta = 25 °C*
Warranty: 5 years
Installation: Pre-wired cable 30 cm 4
Spigot: 40 mm / 42 mm / 60 mm / 76 mm 5
Socket: NEMA Top / Zhaga Top and Bottom
Intelligent control: Stand-alone / Group / CMS
Sensor: Motion / Motion + Daylight / Daylight
Surge protection: 4 / 6 / 10 kV 6
Corrosion protection: Up to C5
Neto weight: Up to 4.6 kg
Max. wind load area, SCd: Up to 0.03 m2
