LAPWING Mushroom | Tool-less
Product Overview
Inspired by the graceful Lapwing bird, the LAPWING luminaire family blends minimalist design with smart functionality. Its clean form captures attention effortlessly, while multiple mounting options ensure a perfect fit for varied urban settings.
Tool-less access, easy installation, and innovative features make LAPWING a reliable choice for both beauty and performance in modern cityscapes.
Basic colours
Specification
V
198 - 264 / 120 - 277 1
Hz
50 - 60
W
5 - 150
lm
Up to 21 780 2
lm/W
Up to 145
K
2700 / 3000 / 4000 3
°C
-40 up to +55 4
CRI
>70 / >80 / >90 3
Body: Die-cast aluminium
Dimming: DALI / 1-10 V / Midnight dimming / Step dimming / Mains dimming
Initial chromaticity: MacAdam 5
Lifetime: Eco 100 000 h (L90B10) at Ta = 25 °C* /
Standard / High density 100 000 h (L98B10) at Ta = 25 °C*
Warranty: 5 years
Installation: Tool-less
Spigot: 40 - 60 mm / 60 - 76 mm
Socket: NEMA Top / Zhaga Top and Bottom
Intelligent control: Stand-alone / Group / CMS
Sensor: Motion / Motion + Daylight / Daylight
Surge protection: 4 / 6 / 10 kV 5
Nature friendly: PC Amber / Red / 1800 K
Corrosion protection: Up to C5
Neto weight: Up to 10.3 kg
Max. wind load area, SCd: 0.05 m2
