LAPWING Top entry | Tool-less
Aperçu du produit
Inspired by the graceful Lapwing bird, the LAPWING luminaire family blends minimalist design with smart functionality. Its clean form captures attention effortlessly, while multiple mounting options ensure a perfect fit for varied urban settings.
Tool-less access, easy installation, and innovative features make LAPWING a reliable choice for both beauty and performance in modern cityscapes.
Couleurs de base
Spécifications
V
198 - 264 / 120 - 277 1
Hz
50 - 60
W
5 - 150
lm
Jusqu'à 24 057 2
lm/W
Jusqu'à 186
K
2700 / 3000 / 4000 3
°C
-40 up to +55 4
CRI
>70 / >80 / >90 3
Body: Die-cast aluminium
Dimming: DALI / 1-10 V / Midnight dimming / Step dimming / Mains dimming
Initial chromaticity: MacAdam 5
Lifetime: Eco 100 000 h (L90B10) at Ta = 25 °C* /
Standard / High density 100 000 h (L98B10) at Ta = 25 °C*
Warranty: 5 years
Installation: Tool-less
Mounting: On console with G3/4 | G1/2 | M32 thread 5
Socket: NEMA Top / Zhaga Top and Bottom
Intelligent control: Stand-alone / Group / CMS
Sensor: Motion / Motion + Daylight / Daylight
Surge protection: 4 / 6 / 10 kV 6
Nature friendly: PC Amber / Red / 1800 K
Corrosion protection: Up to C5
Neto weight: Up to 11.2 kg
Max. wind load area, SCd: 0.04 m2
