STONE

Product Overview

Classic, waterproof industrial linear luminaire which is well dedicated for using in a wide variety of premises and projects: warehouses, parking garages, utility rooms, factories, laboratories, cooking areas, freezers, as emergency luminaire, etc. Stone offers two mounting options – Surface & Pendant. With its polycarbonate body and cover it ensures the highest IP and IK protection required for these specific areas.

Basic colours

  • Gray

Specification

V

220 - 240

Hz

50 - 60

W

10 - 50

lm

1300 - 5800 1

lm/W

122 - 139

K

3000 / 4000 / TW 2700 - 6500 2

-40 to +35

CRI

>80 / >90 / >95 3
>90 / >95 4

Body: Light grey polycarbonate (PC)

Dimming: DALI / Bluetooth / Non dimmable

Sensor: Microwave

Initial chromaticity: MacAdam 3

Lifetime: 100 000 h (L80B10) at Ta = 25 °C*

                 50 000 h (L90B10) at Ta = 25 °C*

Warranty: 5 years

                  2 years (emergency configuration)

Mounting: Surface / Pendant

Cover: Opal palycarbonate (PC)

Human Centric Lighting: Available

Ambient temperature  -15 ... +35°C  |  non dimmable 5

                                        -25 ... +35°C  |  dimmable 5

                                        -40 ... +35°C  |  freezers 5

                                           0 ... +35°C  |  emergency

Class I
IP65
IP66
IP67
IK08
CE
RoHS
Byggvarubedömningen Accepted
Emergency lighting
SundaHus assessment available 6
LED module replaceable by a professional
LED driver replaceable by a professional

1 Lumen output indicated at CRI > 70
2 1800 / 2200 / 2700 / 3500 / 5000 / 5700 / 6500 K available on request along with other not listed CRI and CCT
3 Standard LED CRI
4 Sun-Mimic LED CRI
5 Minus °C temperature applicable only when ventilation glands are ordered as accessories
6 Check SundaHus web page for product assessment results

*This value is only informative and may change according to selected article. LED Lifetime is strongly depending from LEDs current and junction temperature – increase in LED current and luminaire power lead to increase of junction temperature and as consequence lifetime decrease. Thus, luminaire models with lower power, lower current (and lower junction temperature) will have higher lifetime than standard models. And high power and high current luminaire models may have negative lifetime deviation comparing to standard models. To receive precise value please contact VIZULO export representatives.

Total lumen output for final product can differ from typical data by 7% due to special conditions of LED manufacturing processes.Lumen output indicated at 4000 K.

Download Documents

Features

Electronics

Controls & Connectivity

Light

Best selling articles

Other options available on request

Flux (lm)
1140
6819
1140
6819
Efficacy (lm/W)
114
139
114
138.6
Power (W)
10
50
10
50
CCT (K)
CCT Lower value = Warmer light Higher value = Cooler light Contact our sales representative to request other values.
  • 3000
  • 4000
Size (mm)
  • 600
  • 1200
  • 1500
Through wiring
  • None
  • 1.5 mm²
Dimming
Control interface: • DALI - Industry standard for digital control of luminaires. • Midnight dimming - Automatically adjusts output level based on preprogrammed schedule. • D4i - Comes equipped with Zhaga socket for external connection of sensors and controllers. By default the socket is mounted on top (other configurations available on request).
  • No dimming
  • DALI
Sensor
  • None
  • Microwave sensor
Model Flux lm Efficacy lm/W Power W CRI CCT K Size mm Dimming LED type Datasheet
ST 010 830 P06SS NN1 NS043300037 1198 119.8 10 80 3000 600 No dimming Standard
ST 010 830 P06SS NN1 MW043300038 1198 119.8 10 80 3000 600 No dimming Standard
ST 010 830 P06SS ND1 NS043300039 1140 114 10 80 3000 600 DALI Standard
ST 010 830 P06SS VN1 NS043300040 1198 119.8 10 80 3000 600 No dimming Standard
ST 010 830 P06SS VN1 MW043300041 1198 119.8 10 80 3000 600 No dimming Standard
ST 010 830 P06SS VD1 NS043300042 1140 114 10 80 3000 600 DALI Standard
ST 010 840 P06SS NN1 NS043300043 1256 125.6 10 80 4000 600 No dimming Standard
ST 010 840 P06SS NN1 MW043300044 1256 125.6 10 80 4000 600 No dimming Standard
ST 010 840 P06SS ND1 NS043300045 1198 119.8 10 80 4000 600 DALI Standard
ST 010 840 P06SS VN1 NS043300046 1256 125.6 10 80 4000 600 No dimming Standard
