OAK Gen2

Product Overview

Functional linear industrial luminaire. Its’ body is made from Alu-zinc to ensure long-lasting and anticorrosion. It offers two mounting types: Surface and Pendant, and a wide range of wiring & connection options: One end connection, Through wiring, Halogen-free wires.

Basic colours

  • Silver

Specification

V

220 - 240

Hz

50-60

W

15 - 110

lm

Up to 17150 1
Up to 17760 2

lm/W

151 - 174

K

3000 / 4000 3

+10 to +50 | 15 - 75W
+10 to +35 | 76 - 110W

CRI

>80 / >90 / >95 4
>90 / >95 5

Body: Alu-zinc

Dimming: DALI / Bluetooth / Non dimmable

Sensor: Microwave / PIR / PIR + Daylight

Initial chromaticity: MacAdam 3

Lifetime: 100 000 h (L80B10) at Ta = 25 °C*

                 50 000 h (L90B10) at Ta = 25 °C*

Warranty: 5 years

                  2 years (emergency configuration)

Mounting: Wire / Surface / Pendant

Cover: Clear

Human Centric Lighting: Available

Class I
IP23
CE
RoHS
International EPD System 6
Emergency lighting
LED module replaceable by a professional
LED driver replaceable by a professional

1 Standard version, lumen output indicated at CRI > 70
2 Premium version, lumen output indicated at CRI > 70
3 1800 / 2200 / 2700 / 3500 / 5000 / 5700 / 6500 K available on request along with other not listed CRI and CCT
4 Standard LED CRI
5 Sun-Mimic LED CRI
6 EPD registration number: S-P-04208 (link to page)

*This value is only informative and may change according to selected article. LED Lifetime is strongly depending from LEDs current and junction temperature – increase in LED current and luminaire power lead to increase of junction temperature and as consequence lifetime decrease. Thus, luminaire models with lower power, lower current (and lower junction temperature) will have higher lifetime than standard models. And high power and high current luminaire models may have negative lifetime deviation comparing to standard models. To receive precise value please contact VIZULO export representatives.

Total lumen output for final product can differ from typical data by 7% due to special conditions of LED manufacturing processes.Lumen output indicated at 4000 K.

Download Documents

Features

Application

Feature glass diffusion hanging plates

Electronics

Light

Best selling articles

Other options available on request

Flux (lm)
1853
15777
1853
15777
Efficacy (lm/W)
124
154
123.5
154.3
Power (W)
15
110
15
110
CCT (K)
CCT Lower value = Warmer light Higher value = Cooler light Contact our sales representative to request other values.
  • 3000
  • 4000
Beam angle
  • Narrow
  • Medium
  • Wide
Size (mm)
  • 600
  • 1200
  • 1500
  • 1800
Through wiring
  • None
  • 1.5 mm²
Dimming
Control interface: • DALI - Industry standard for digital control of luminaires. • Midnight dimming - Automatically adjusts output level based on preprogrammed schedule. • D4i - Comes equipped with Zhaga socket for external connection of sensors and controllers. By default the socket is mounted on top (other configurations available on request).
  • No dimming
  • DALI
Sensor
  • None
  • Microwave sensor
Model Flux lm Efficacy lm/W Power W CRI CCT K Beam angle Size mm Dimming LED type Datasheet
OK 015 830 CN06 CZ NN1 NS068101275 1853 123.5 15 80 3000 Narrow 600 No dimming Standard
OK 015 830 CN06 CZ NN1 MW068101276 1853 123.5 15 80 3000 Narrow 600 No dimming Standard
OK 015 830 CN06 CZ ND1 NS068101277 1945 129.7 15 80 3000 Narrow 600 DALI Standard
OK 015 830 CN06 CZ ND1 MW068101278 1945 129.7 15 80 3000 Narrow 600 DALI Standard
OK 015 830 CM06 CZ NN1 NS068101279 1885 125.7 15 80 3000 Medium 600 No dimming Standard
OK 015 830 CM06 CZ NN1 MW068101280 1885 125.7 15 80 3000 Medium 600 No dimming Standard
OK 015 830 CM06 CZ ND1 NS068101281 1978 131.9 15 80 3000 Medium 600 DALI Standard
OK 015 830 CM06 CZ ND1 MW068101282 1978 131.9 15 80 3000 Medium 600 DALI Standard
OK 015 830 CW06 CZ NN1 NS068101283 1917 127.8 15 80 3000 Wide 600 No dimming Standard
OK 015 830 CW06 CZ NN1 MW068101284 1917 127.8 15 80 3000 Wide 600 No dimming Standard
